Photo etched flat springs

We supply photo-etched flats springs of precision-accuracy for a wide range of applications.

What are flat springs?

Flat springs, also called leaf or beam springs, are made to store and release energy when flexed. With a distinctive flat design, they come in various shapes and sizes to suit specific applications, and can be manufactured from a variety of sheet metals.

Precision photo etched flat springs

Unlike stamping and other traditional machining methods, chemical photo etching can produce custom flat springs that are 100% free of burrs, stress, and material degradation.

Our photo etching process involves selectively removing material from sheet metal with chemical solution and UV photoresist—eliminating the potential for burrs or stress—without altering the mechanical properties of the spring material. This effectively maintains attributes such as flatness, recoil, and fatigue strength to produce springs accurate within ±0.020mm of design specifications.

Benefits of photo chemical etching

  • 100% burr and stress-free springs
  • Accurate within ±0.020mm [0.0005″]
  • Low-cost prototyping
  • Scalable mass production

Flexible flat spring production

We can manufacture flat springs from all grades of spring steel. Whether you need prototype quantities or high-volume production, we use digital tooling to keep costs low and deliver prototypes in just a couple of days. With offer more than 55 years of expertise in creating photo etched springs for a wide range of applications and industries.

Medical

Cochlear implants, diagnostic equipments, surgical tools

Automotive

Catalytic converters, fuel injection systems, sensors

Aerospace

Electrical connectors, contacts, cryogenics

Electronics

Microphone diaphragm, camera springs, connectors

Computers

Heat sinks, battery contacts,
shielding

Ready to get started with your component design?
